FIXER X Series

FIXER XC

FIXER XC is a High speed powered drain cleaning machine, that can accommodate both Ø10 mm / 0.39 in and Ø12 mm / 0.47 in shafts.

Buy NowSpecification

Pipe diameter
DN70-250
Weight without shaft
55.5 kg

Specification

Size cm / inches
121 × 42 × 103 cm / 47.6 × 16.5 × 40.6 in
Weight kg / lb
Without shaft 55.5 kg / 122.4 lb
With Ø10 shaft 74.5 kg / 164.24 lb
With Ø12 shaft 78 kg / 172 lb
Shaft Ø mm / inches
Ø10 (0.39") or Ø12 (0.47") flexible shaft with outer casing
Shaft Length m / feet
30.5 m / 100.1 ft or 25 m / 82.0 ft
Rotating max. speed rpm
Adjustable speed, max. 2250 rpm.
Voltage & power rating V / kW
240 V / 1.5 kW (available in 120 V)
Input Power
Electric, 1-phase, 220-240 VAC / 50-60 Hz / 16 A
Electric, 1-phase, 110-120 VAC / 50-60 Hz / 23 A
IP Class
54
Diameter mm / inches
DN70-250 / 3”-10”
Other
Adjustable speed control, direction switch, foot pedal (OPC), emergency stop, electronic safety switch, PU foam wheels, robust metal frame.

FIXER X in action

FIXER XC

Tools

Various tools for FIXER X series products

Improve the performance and efficiency of your work with tools that can be connected to FIXER.

Find out more

Drain cleaning tools: chain, grinding hub, opening drill head and cyclone chain

Accessories

Lining materials and accessories, including a blue protective glove

Find out more about Fixaline's accessories

Through us you can get all the accessories for daily work. Find out more and order directly from our online store.

Find out more

Meet FIXER X pipe cleaning series
